Impact mill special for ceramic colorants

Equipment Selection:

Based on the physical characteristics of ceramic colorants, various equipment is employed for crushing and classification to achieve optimal output ratio. Our company's specialized graded Impact Mill (effectively reducing energy consumption of production equipment) is capable of achieving satisfactory crushing results. For ceramic raw materials (such as feldspar, porcelain clay, bauxite, etc.) and ceramic colorants (like chrome green, orange, iron oxide red, etc.), a fluidized bed jet mill (featuring low crushing temperature, preventing the melting and adhesion of oily and sugary substances to the equipment at low temperatures) can be utilized for crushing and classification. Additionally, ceramic raw materials and ceramic colorants (glazes, frits, etc.) can be processed using air classification equipment.

Equipment Features:

1. Purity Assurance: Impurities are prevented from mixing into the materials, ensuring high-quality output. Without the need for water or washing, the completely dry production process achieves better particle size distribution and pollution-free ultrafine powder in a single production cycle, with a single-grade yield rate exceeding 75%. The system incorporates comprehensive, stable, and uniform flow field control technology; a constant gas-solid concentration ratio design within the crushing chamber ensures stable long-term operation. Rational flow field design and special wear-resistant treatment for vulnerable parts significantly reduce equipment wear, prolonging its service life. High classification accuracy, precise cut size, lower required rotational speed, and long service life are also notable features.



2. Excellent Particle Shape: Under fully fluidized conditions, exceptionally spherical particle shapes are achieved. Qualified ultrafine powder is immediately classified, preventing over-crushing. Our unique variable frequency feeding system aids in material dispersion, ensuring continuous, uniform, and stable feeding, contributing to precise particle size control.

3. Precise Classification: The efficient and high-precision classifier establishes a complete and stable flow field, strictly regulating particle generation and achieving excellent particle size distribution within a narrow range. In particular, the core competitive advantage of thorough and stable fine powder extraction has gained wide industry recognition.

4. High Purity and Low Wear: Wear-resistant materials can be lined inside the equipment, resulting in high-purity products and reduced equipment wear.

5. Stable Operation: Once adjusted and set, the equipment operates stably without any differences or changes during prolonged continuous operation.

6. Environmentally Friendly: Fully enclosed negative pressure operation ensures low-temperature crushing, high-purity processing, and dust-free production, with system emissions ≤5mg/m³. The crushing chamber is equipped with an automatic slagging device to eliminate hard-to-grind particles and impurities from the material. It also possesses agglomerate dispersion and distribution capabilities. The high-flow air capacity facilitates cooling during grinding, suitable for processing heat-sensitive materials without deposition issues. The system is automated, low-noise, and dust-free.

Ceramic Colorant Crushing Equipment Parameters:
