jet mill and classifier for abrasive powders

Get Latest Price

Min. Order:

1 Set/Sets

Contact Now

Product Description

Product Attributes
Packaging & Delivery

< >

Overview

Product Attributes

Applicable Industry: Manufacturing Plant

Packaging & Delivery

Selling Units:: Set/Sets

Equipment Features:

Completely dry production without the use of water or water washing, achieving abrasive powders with narrower particle size distribution and no pollution.
High classification accuracy, more precise cutting particle size, lower required rotation speed, and long service life.
Independent cast bearing seat, never deformed, and long service life.
Optimized transmission design, reducing bearing stress and extending service life.
Unique pipeline design, facilitating powder flow, reducing wear, and making vulnerable parts easy to replace and handle.
The company's unique feeding system helps with material dispersion, ensuring continuous, uniform, and stable feeding, which contributes to product particle size control.
Unique internal circulation secondary air design and classification cone gap design significantly reduce air consumption, lower classification energy consumption, and thoroughly extract fine powder.
The separation of flow paths helps slow down the wear at the bottom of the Classifier Wheel and better control large particles.

Fully enclosed negative pressure operation, no dust pollution, good stability, and stable production after adjusting and fixing parameters once.

Equipment Parameters:

Model	Feed Particle Size	Discharge Particle Size	Processing Capacity	Installed Power	Length x Width x Height (m)
SCWN-Q400	＜100 mesh or finer	JIS standard: 280# to 3000#	60-300kg/h	＜160kw	12x2x6
SCWN-F400-2	＜100 mesh or finer	JIS standard: 1000# to 3000#	800-1000kg/h	＜57kw	12x2x6
SCWN-F400-3	＜100 mesh or finer	JIS standard: 1000# to 3000#	800-1000kg/h	＜65kw	13x2x6

Product Categories : Pharmaceutical And Food Ultra-fine Grinding Mill
