Food-grade Ultrafine Grinding Machine

Get Latest Price

Min. Order:

1 Set/Sets

Contact Now

Product Description

Product Attributes
Packaging & Delivery

< >

Overview

Product Attributes

Applicable Industry: Manufacturing Plant

Packaging & Delivery

Selling Units:: Set/Sets

Equipment Features:

Unique multi-force field grinding ensures high efficiency and intense crushing power for soft and fibrous materials, effectively breaking the cell walls of substances like Ganoderma lucidum.

A reasonable cooling flow field prevents the deterioration of traditional Chinese medicinal materials due to localized temperature rise. The low grinding temperature ensures the natural attributes and quality of processed pharmaceuticals and healthcare products.

The product is pollution-free, with a smooth inner shell surface that is easy to clean. It occupies a small footprint, generates low noise, and has no vibration. It has a wide range of applications, and the products processed by this series of equipment all meet the GMP standards for pharmaceuticals.

Working Principle:

The material enters the self-dividing grading zone through the feeding system for the initial grading. Most of the coarse particles are separated, while the fine powder, along with a small amount of coarse particles, is carried into the turbine grading zone by the rising airflow for secondary grading. The fine powder passes through the grading wheel and is collected in the collector, while the coarse particles are discharged through the discharge valve of the classifier.

Technical Parameters:

Specification/Model	Feed Particle Size	Discharge Particle Size	Production Capacity	Installed Power	Air Consumption
SCWN-SPYP36	＜3mm	2-100um	80-360kg/h	35-41kw	6m³/min
SCWN-SPYP120	＜3mm	2-100um	350-1200kg/h	85-154kw	20m³/min
SCWN-SPYP240	＜3mm	2-100um	650-2500kg/h	185-311kw	40m³/min

Product Categories : Air Jet Mill
